Miniature Flow Switch with Fixed Set Point FS series

2425 INR

Get a Price/Quote

Product Details:

Mechanical Life Over 1,000,000 operations
Protection Level IP65
Temperature Range -20C to +80C
Response Time 5ms
Rated Voltage 250V AC/DC
Finish Type Polished Metal
Number of Module Single
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Miniature Flow Switch with Fixed Set Point FS series Price And Quantity

Minimum Order Quantity 1 Piece
Price 2425 INR

Miniature Flow Switch with Fixed Set Point FS series Product Specifications

Stoke 2~3mm
Product Type Miniature Flow Switch with Fixed Set Point FS series
Max. Voltage 250V AC/DC
Mechanical Life Over 1,000,000 operations
Operating Temperature -20C to +80C
Insulation Resistance 100M at 500VDC
Weight Approx. 80g
Automation Grade Manual/Automatic
Contact Resistance 100m
Number of Module Single
Protection Level IP65
Finish Type Polished Metal
Mounting Type Inline Threaded
No Of Poles Single Pole
Rated Voltage 250V AC/DC
Max. Current 0.5A
Response Time 5ms
Circuit Type SPST Normally Open or Normally Closed
Temperature Range -20C to +80C
Current Rating 0.5A Max

Miniature Flow Switch with Fixed Set Point FS series Trade Information

Payment Terms Cheque
Supply Ability 1 Piece Per Day
Delivery Time 2 - 3 Week
Packaging Details Carton Box
Main Export Market(s) Western Europe, Australia, Eastern Europe, Middle East, Central America, Africa, South America, Asia, North America
Main Domestic Market All India

Product Description

FS series Switches are not suitable if the fluid carries suspended particles of size more than 50 microns.

WPFS series Flow Switches are suitable even though the fluid carries suspended particles of size more than 50 microns.

Any non-magnetic liquids or, gases

Note : To receive quick response, please provide your basic requirement details and max.Application information.

Service	Any non-magnetic liquids or, gases
Series	FS series or, WPFS series
Mounting	On vertical or, horizontal pipe line
Process connection	1/4, 3/8,1/2, 3/4 or, 1
Flow Switch set point	Prefixed or, Field Settable
Electrical connection	Flying Leads or, DIN connector
Wetted Part	SS 304 or, SS 316
Switch type	SPST (NO) Reed Switch (10 VA 230 VAC) / SPDT Reed Switch (10 VA 230 VAC)
Repeatability	Better than +/- 1%
Accuracy	+/-2.0 %
Max. Working Pressure	10 bar
Max. Working Temperature	80 degree C

Reliable Precision for Fluid Flow Detection

The FS series flow switch ensures dependable operation, featuring a fixed set point for flow rate between 0.6 and 1.5 L/min. With minimal hysteresis and high mechanical life, the reed switch mechanism guarantees consistent flow detection for water, oil, and air systems. Its robust build and compatibility with a range of pipe diameters support varied industrial applications, making it a practical choice where reliability is crucial.

Versatile Installation and Outstanding Durability

Designed for easy inline threaded mounting and usable in any orientation, this flow switch simplifies installation across diverse setups. Its IP65 rating protects against dust and water, while the wide operating temperature range from -20C to +80C ensures suitability in challenging environments. The polished metal finish and compact design further aid in longevity and maintenance.

FAQs of Miniature Flow Switch with Fixed Set Point FS series:

Q: How should the Miniature Flow Switch FS series be installed?

A: The FS series flow switch can be installed in any orientation thanks to its versatile design. Ensure the inline threaded mount matches your pipe diameter (DN6 to DN10) and secure it according to manufacturer instructions to guarantee optimal performance.

Q: What types of media are compatible with this flow switch?

A: This flow switch is built to handle water, oil, air, and non-corrosive fluids, making it suitable for a range of industrial and automation applications. Avoid using it with aggressive corrosive substances to preserve the integrity of the device.

Q: When is it appropriate to use this flow switch in a fluid system?

A: This flow switch is ideal for systems requiring precise flow monitoring within 0.6 to 1.5 L/min, such as cooling circuits, lubrication lines, or pneumatic setups in industrial environments, particularly where reliability and fast response are required.

Q: Where can this product be sourced in India?

A: The FS series Miniature Flow Switch is available through various dealers, distributors, exporters, manufacturers, service providers, and suppliers throughout India. Contact your preferred automation or instrumentation equipment supplier for availability.

Q: What is the process for connecting the flow switch electrically?

A: The device offers either lead wires or terminal connections. Depending on your circuit requirements, connect it to your control system at a voltage up to 250V AC/DC and a maximum current of 0.5A, ensuring proper SPST configuration according to your systems needs.

Q: How does the switching element and circuit type function in operation?

A: Utilizing a reed switch with an SPST (single pole single throw) configuration, the device provides either a normally open or normally closed contact depending on your selection. The switching occurs quickly (5ms) once the fixed flow set point is reached.

Q: What are the main benefits of using this FS series flow switch?

A: Key benefits include high reliability (over 1,000,000 mechanical operations), compatibility with multiple fluids, rapid response, IP65 protection, flexible installation, and maintenance-free operation due to its durable, polished metal construction.

Tell us about your requirement

Price:

Quantity

Select Unit

50
100
200
250
500
1000+

Additional detail

Mobile number

Other Products in 'Flow Switches' category

ATEX certified Paddle type Flow Switches Price : 6500 INR/Piece Minimum Order Quantity : 1 Product Type : ATEX certified Paddle type Flow Switches Temperature Range : 20C to +80C Contact Resistance : 50m Automation Grade : Automatic Number of Module : Single Protection Level : IP65 (ATEX II 2G Ex d IIC T6 Gb) Finish Type : Polished/Coated No Of Poles : Single Pole Max. Current : 5A Mounting Type : Inline Threaded Rated Voltage : 250V AC Response Time : <1 second Circuit Type : SPDT Current Rating : 5A @ 250V AC Max. Voltage : 250VAC/30VDC Mechanical Life : 1,000,000 operations Operating Temperature : 20C to +80C Insulation Resistance : 100M (500VDC) Weight : Approx. 0.91.2 kg Stoke : 5 mm (typical)

Send Inquiry

Flameproof Magnetic Paddle type Flow Switch Series Price : 2300 INR Minimum Order Quantity : 1 Product Type : Flameproof Magnetic Paddle type Flow Switch Series Temperature Range : 20C to +60C Contact Resistance : <50 m Automation Grade : Automatic Number of Module : Single Protection Level : IP65 / Flameproof as per IS/IEC 600791 Finish Type : Flameproof enclosure with corrosionresistant coating No Of Poles : Single Pole Double Throw (SPDT) Max. Current : 5A Mounting Type : Inline, Threaded connection Rated Voltage : 250 V AC/DC Response Time : <2 seconds Circuit Type : SPDT Current Rating : 5A @ 250V AC Max. Voltage : 250 V AC/DC Mechanical Life : 1,000,000 operations Operating Temperature : 20C to +60C Insulation Resistance : 100 M at 500 VDC Weight : Approx. 1.2 kg Stoke : Adjustable by paddle length
